The FD5000S medium voltage inverter is a kind of digital signal processor as the core, space voltage vector PWM as the core, battery serial multilevel technology as the core, to meet the requirements of various applications. In 2005, the company won the title of national Key new product, and won the National Torch Program, and won the support of the Ministry of Science and Technology Small and medium-sized enterprises Science and Technology Innovation Fund.

FD5000S medium voltage inverter is composed of phase shifting transformer, power battery and control unit.

● Voltage: 13.8kV

● Power: 250~20000kW

● Control Mode: V/f, Vector control

● OEM/ODM: Yes

● Supply Ability: 3000 Sets per Year

Inquiry

Free Quote & Information Request

Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.

Product Description

FD5000S series is single side operation, only front door can be opened for
operation , and it’s suitable for limited installation space. 3kV, 3.3kV has three
power cells.

11kV has 9 power cells for one phase, totally 27 cells for three phase.

FD5000S series MVD has better adaptability to voltage fluctuations, and
automatic recover when the main power supply has instantaneous power
outage, sudden drop, or power grid switching.
Product advantages

● Synchronous switching (optional function): Realize smooth switching from MVD to the power grid or from the power grid to MVD.
● Comprehensive protection functions: Perfect protection functions to ensure system to be safe and reliable
● Anti-interference design: The entire cabinet adopts anti-interference design, better EMC performance.
● Multiple control modes: V/f, Vector control. Local, Remote control, Modbus, Profibus

Product Display

Modularized design
————— + —————
Easy installation
Easy maintenance
High reliability
Customized design
Single side operation
————— + —————
Only front door can be opened for operation
Suitable for limited installation space
Compatible motors
————— + —————
High voltage permanent magnet synchronous motor
High voltage asynchronous motors

Product Applications
