It is applicable to mechanical fans, pumps, conveyor line automation equipment and machine tools (such as CNC machine tools, machining centers) in industries like metallurgy, chemical engineering, textile, pharmaceuticals, printing, packaging and food. It features stepless speed regulation, a wide speed regulation range, excellent system speed regulation performance, and more significant energy-saving effects. It adopts insulating materials and processes that can withstand high-frequency pulse voltage impact, and is cooled by forced ventilation with an independent fan.

● Frame Size: H80-H355

● Rated Power: 0.37-375kW

● Rated Voltage: 380V

● Rated Frequency. 2P：5-100Hz;4P,6p,8p,10p:5-75\100Hz

● Poles: 2p,4p,6p,8p,10p

● Protection grade：IP54
